Power Distribution Unit

Raritan PX3-5746X2. PDU types: Monitored, Switched, Rack capacity: 0U, Type: Single-phase. AC outlets quantity: 20 AC outlet(s), AC outlet types: C13 coupler, C19 coupler, Power plug: IEC 320. LED indicators: Status, Cable length: 118.1" (3 m). Monitoring: Humidity, Temperature. Nominal input voltage: 208 V, Maximum current: 20 A, AC input frequency: 50 - 60 Hz

Panduit P16D12M

Raritan PX3-4496V. PDU types: Monitored, Rack capacity: 0U, Type: Single-phase. AC outlets quantity: 24 AC outlet(s), AC outlet types: C13 coupler, Power plug: IEC 320. LED indicators: Status, Cable length: 118.1" (3 m). Monitoring: Humidity, Temperature. Nominal input voltage: 208 V, Maximum current: 30 A, AC input frequency: 50 - 60 Hz

Raritan PX3-5466V. PDU types: Metered, Monitored, Switched, Rack capacity: 0U, Mounting: Vertical. Input connection type: IEC 60309 2P+E 6h 32A (2P3W). Cable length: 118.1" (3 m), Certification: CE, ICES-003, FCC. Monitoring: Humidity, Temperature. Nominal input voltage: 230 V, Maximum current: 32 A, AC input frequency: 50 - 60 Hz

Tripp Lite PDU3MV6H50. PDU types: Metered, Rack capacity: 0U, Mounting: Horizontal/Vertical. AC outlets quantity: 45 AC outlet(s). Cable length: 72" (1.83 m), Certification: UL60950-1 NOM. Nominal input voltage: 208 V, Maximum current: 35 A, Nominal output voltage: 208 V. Width: 2.2" (55.9 mm), Depth: 2.65" (67.3 mm), Dimensions (WxDxH): 2.64 x 2.2 x 70" (67 x 56 x 1778 mm)

Eaton EMI101-10. PDU types: Monitored, Rack capacity: 38U-A, Mounting: Vertical. AC outlets quantity: 24 AC outlet(s), AC outlet types: NEMA 5–20R, Input connection type: 1 x 5-20P & 1 x L5-20P. Cable length: 118.1" (3 m), Certification: UL60950-1. Nominal input voltage: 120 V, Maximum current: 16 A, AC input frequency: 50 - 60 Hz. Dimensions (WxDxH): 2.05 x 2.1 x 66.5" (52.1 x 53.3 x 1689.1 mm)

Vertiv I10109L. PDU types: Basic, Rack capacity: 1U, Mounting: Horizontal. AC outlets quantity: 6 AC outlet(s), AC outlet types: C19 coupler. Cable length: 118.1" (3 m), Certification: RoHS Compliant, FCC Part 15 Class A Conformance, UL & c-UL Listed 62368-1. Nominal input voltage: 346-415 V, Maximum current: 30 A, AC input frequency: 50/60 Hz. Width: 19" (483 mm), Depth: 8.5" (215.9 mm), Height: 1.72" (43.6 mm)

APC AP8862. PDU types: Metered, Mounting: Horizontal/Vertical, Product color: Black. AC outlets quantity: 36 AC outlet(s), AC outlet types: NEMA 5–20R, Power plug: NEMA L21-20P. Cable length: 72" (1.83 m), Certification: cUL Listed, FCC Part 15 Class A, ICES-003, UL 60950-1, UL Listed. Nominal input voltage: 208 V, AC input frequency: 50 - 60 Hz, Nominal output voltage: 120 V. Dimensions (WxDxH): 2.17 x 1.73 x 70.5" (55 x 44 x 1791 mm), Weight: 13.3 lbs (6.04 kg)

APC AP8841. Product color: Black. Input connection type: NEMA L6-30P, Output connections: 36x IEC 320 C13 6x IEC 320 C19. Cable length: 118.1" (3 m), Certification: CSA C22.2 No. 60950,IEC 60950,METI Denan,UL 60950-1,VDE RoHS,REACH. AC input frequency: 50 - 60 Hz, Maximum input current per phase: 30 A, Maximum total current draw per phase: 30 A. Dimensions (WxDxH): 2.2 x 1.73 x 70.5" (56 x 44 x 1791 mm), Weight: 15.1 lbs (6.84 kg)

Vertiv I10087. PDU types: Metered, Mounting: Vertical, Product color: Black. AC outlets quantity: 24 AC outlet(s), AC outlet types: NEMA 5-20R, Power plug: NEMA L21-30P. Cable length: 118.1" (3 m), Certification: RoHS Compliant, FCC Part 15 Class A Conformance, UL & c-UL Listed 62368-1. Nominal input voltage: 200-240 V, Maximum current: 30 A, AC input frequency: 50/60 Hz. Width: 2" (50.8 mm), Depth: 2.24" (57 mm), Height: 66.3" (1683 mm)

APC Rack PDU 2G. PDU types: Metered, Mounting: Horizontal/Vertical, Product color: Black. AC outlets quantity: 30 AC outlet(s), AC outlet types: NEMA 5–20R, NEMA L6-20R, Input connection type: NEMA L21-20P. LED indicators: Alarm, Cable length: 72" (1.83 m), Certification: cUL Listed, FCC Part 15 Class A, ICES-003, UL 60950-1, UL Listed, REACH. Monitoring: Current. Nominal input voltage: 208 V, Maximum current: 20 A, AC input frequency: 50 - 60 Hz

Raritan PX3-5460V-C5. PDU types: Managed, Metered, Monitored, Switched, Rack capacity: 0U, Mounting: Vertical. AC outlets quantity: 20 AC outlet(s), AC outlet types: C13 coupler, Input connection type: NEMA L6-30P (2P3W). Cable length: 118.1" (3 m), Certification: UL, ICES-003, FCC. Monitoring: Humidity, Temperature. Nominal input voltage: 208 V, Maximum current: 30 A, AC input frequency: 50 - 60 Hz

Eaton TPC3225. PDU types: Basic, Rack capacity: 1U, Mounting: Horizontal. AC outlets quantity: 10 AC outlet(s), AC outlet types: NEMA 5–15R. Cable length: 118.1" (3 m). Nominal input voltage: 110 V, Maximum current: 4 A. Dimensions (WxDxH): 19 x 6.97 x 1.69" (482 x 177 x 43 mm)

Tripp Lite PDUMV20HVNETLX. PDU types: Switched, Rack capacity: 0U, Type: Single-phase. AC outlets quantity: 24 AC outlet(s), AC outlet types: C13 coupler, C19 coupler, Power plug: C20 coupler. LED indicators: Power, Status, Cable length: 120.1" (3.05 m), Certification: TAA, UL, CE, FCC, NOM, EN55022:2010+2011, EN55024:2010. Supported network protocols: HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP, NTP. Nominal input voltage: 200-240 V, Maximum current: 20 A

Eaton EBA201-10. PDU types: Basic, Rack capacity: 0U, Mounting: Vertical. AC outlets quantity: 24 AC outlet(s), AC outlet types: NEMA 5-20R, Power plug: NEMA L14-30P. Cable length: 118.1" (3 m). Nominal input voltage: 120-240 V, Maximum current: 24 A, AC input frequency: 50/60 Hz

Tripp Lite PDUMH30HVNET. PDU types: Switched, Rack capacity: 2U, Mounting: Horizontal. AC outlets quantity: 16 AC outlet(s), AC outlet types: C13 coupler, Power plug: NEMA L6-30P. Cable length: 141.7" (3.6 m), Certification: UL 60950-1, Class A, NOM. Nominal input voltage: 200-240 V, Maximum current: 30 A, AC input frequency: 50 - 60 Hz. Width: 17.5" (444.5 mm), Depth: 12.5" (317.5 mm), Dimensions (WxDxH): 17.5 x 12.5 x 3.5" (445 x 317.5 x 89 mm)

Raritan PX3-5453R. PDU types: Metered, Monitored, Switched, Rack capacity: 2U, Mounting: Horizontal. AC outlets quantity: 20 AC outlet(s), AC outlet types: NEMA 5–20R, Input connection type: NEMA L5-30P (2P3W). Cable length: 118.1" (3 m), Metering: Voltage, Current, Active Power, Real Power, Energy, Power Facrot. Nominal input voltage: 120 V, Maximum current: 30 A, AC input frequency: 50 - 60 Hz. Dimensions (WxDxH): 17.3 x 11.5 x 3.46" (440 x 292 x 88 mm), Weight: 15 lbs (6.8 kg)

Vertiv I10086. PDU types: Metered, Mounting: Vertical, Product color: Black. AC outlets quantity: 33 AC outlet(s), AC outlet types: C13 coupler, C19 coupler, NEMA 5-20R, Power plug: NEMA L21-30P. Cable length: 118.1" (3 m), Certification: RoHS Compliant, FCC Part 15 Class A Conformance, UL & c-UL Listed 62368-1. Nominal input voltage: 200-240 V, Maximum current: 30 A, AC input frequency: 50/60 Hz. Width: 2" (50.8 mm), Depth: 2" (50.8 mm), Height: 72" (1829 mm)
