Trendnet TI-PG262 network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

Trendnet TI-PG262. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. MAC address table: 8000 entries, Switching capacity: 52 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z. DC input voltage: 48 - 56 V. Power over Ethernet (PoE). Wall mountable
Manufacturers: TRENDNET INC , Trendnet
SKU: 7817585
Manufacturer part number: TI-PG262
GTIN: 0710931162585
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
TRENDnet’s Industrial Gigabit PoE+ DIN-Rail Switches feature a rugged IP30 rated metal enclosure. These Industrial Unmanaged PoE+ Switches are designed to withstand a high degree of vibration and shock, while operating in both high and low temperatures for industrial environments within -40° – 75° C (-40° – 167° F). Redundant power inputs with overload current protection on each industrial unmanaged PoE+ switch minimizes network downtime. TI-PG262 Installers and integrators can save on equipment costs and reduce installation time with TRENDnet’s Industrial Gigabit PoE+ Switches by delivering up to 30W per port of PoE power and data over existing Ethernet cables. With PoE technology, users only need one set of cables to deliver both data and power from the industrial unmanaged PoE+ switch. With these industrial unmanaged PoE+ switches, easily network PoE devices, such as high-power wireless access points, PTZ and other advanced IP cameras, VoIP phone systems, IPTV decoders, access controls, and more.



  • 16 x Gigabit PoE+ ports
  • 8 x Gigabit ports
  • 2 x 100/1000Mbps SFP ports
  • Up to a 480 watt full PoE+ power budget
  • 52Gbps switching capacity
  • Hardened IP30 rated metal switch
  • Includes DIN-Rail and wall mounts
  • Extreme -40 to 75 ºC (-40 to 167 ºF) operating temperature range
  • Redundant power inputs with overload current protection
  • Alarm output triggered by power failure
  • Powers supply sold separately (Model TI-S48048)
  • NDAA / TAA compliant (U.S. and Canada only)
TRENDnet’s Industrial Gigabit PoE+ DIN-Rail Switches feature a rugged IP30 rated metal enclosure. These Industrial Unmanaged PoE+ Switches are designed to withstand a high degree of vibration and shock, while operating in both high and low temperatures for industrial environments within -40° – 75° C (-40° – 167° F). Redundant power inputs with overload current protection on each industrial unmanaged PoE+ switch minimizes network downtime. TI-PG262 Installers and integrators can save on equipment costs and reduce installation time with TRENDnet’s Industrial Gigabit PoE+ Switches by delivering up to 30W per port of PoE power and data over existing Ethernet cables. With PoE technology, users only need one set of cables to deliver both data and power from the industrial unmanaged PoE+ switch. With these industrial unmanaged PoE+ switches, easily network PoE devices, such as high-power wireless access points, PTZ and other advanced IP cameras, VoIP phone systems, IPTV decoders, access controls, and more.



  • 16 x Gigabit PoE+ ports
  • 8 x Gigabit ports
  • 2 x 100/1000Mbps SFP ports
  • Up to a 480 watt full PoE+ power budget
  • 52Gbps switching capacity
  • Hardened IP30 rated metal switch
  • Includes DIN-Rail and wall mounts
  • Extreme -40 to 75 ºC (-40 to 167 ºF) operating temperature range
  • Redundant power inputs with overload current protection
  • Alarm output triggered by power failure
  • Powers supply sold separately (Model TI-S48048)
  • NDAA / TAA compliant (U.S. and Canada only)
Products specifications
Attribute nameAttribute value
Width6.1"
Depth4.72"
Height3.07"
Weight31.7 oz
Switch TypeUnmanaged
Power SourceDC/PoE
SFP module slots quantity2
Switching capacity52 Gbit/s
Power over Ethernet (PoE) power per port30 W
Port mirroringYes
Forwarding rate38.6 Mpps
Power over Ethernet (PoE) type supportedPoE+
Half duplexYes
Features
LED indicatorsYes
Wall mountableYes
Mean time between failures (MTBF)503149 h
Design
CertificationCE FCC LVD
DIN rail mountingYes
Operational conditions
Operating temperature (T-T)-40 - 75 °C
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Power over Ethernet plus (PoE+) ports quantity16
Performance
Networking standardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Network
Jumbo frames supportYes
Auto-negotiationYes
Jumbo frames9000
10G supportYes
Power over Ethernet (PoE)
Power over Ethernet (PoE)Yes
Technical details
Product colorBlack
Power
Total Power over Ethernet (PoE) budget480 W
Power consumption (max)5.76 W
DC input voltage48 - 56 V
Other features
MAC address table8000 entries
Data transmission
Store-and-forwardYes
*
*
*
